MIDAS DL32 Digital Stage I/O Box with 32 Midas Microphone Preamp input, 16 Outputs, ULTRANET & ADAT Interfaces - Brand New

MIDAS DL32 Digital Stage I/O Box with 32 Midas Microphone Preamp input, 16 Outputs, ULTRANET & ADAT Interfaces - Brand New

Regular price ₦2,995,000.00 NGN
Regular price Sale price ₦2,995,000.00 NGN
Sale Sold out
Tax included. Shipping calculated at checkout.

The MIDAS DL32 Digital Stage Box is a powerful tool for any sound engineer. With 32 Midas Microphone Preamps, this stage box provides unparalleled sound quality and control. It also features 16 outputs, ULTRANET, and ADAT interfaces, making it versatile and adaptable for any live or studio setting. Increase your productivity and elevate your sound with the MIDAS DL32 Digital Stage Box - a must-have for professionals.

  • Digital mixing has revolutionized virtually everything in the live-entertainment production workflow.
  • The DL32 is the perfect solution for connecting the onstage talent with your Front of House (FOH) console, and the rest of the world – the I/O packed and highly affordable DL32 digital stage box.
  • The DL32 provides 32 Midas PRO Series remote-controllable mic preamps, plus 16 balanced analog XLR returns at the stage end – and all it takes is a single Cat 5e cable.
  • While Klark Teknik, the industry-leader in high-end digital audio processing, invented the AES50 SuperMAC technology that made it all possible – our superb scale of production makes the DL32 so very affordable.
  • The DL32 was initially designed with our M32 Digital Mixing Console in mind, but any mixingboard with AES50 networking capability can still tap directly into the DL32’s powerful feature set. For instance, a DL32 and M32C could be jointly utilised to create a remote controlled digital mixingsystem in only 4U.
  • Another prime application might include the M32C providing independentmonitor mix duties, while also relaying and sharing all I/O with the main console – an M32, or anyother digital mixer that supports MADI, Dante, ADAT or AES50 I/O.
  • Reasonably priced option cards to replace the standard 32 x 32 channel USB interface are separately available for that exact purpose.
  • You can even mix the complete show from the onstage M32C via dedicated remote control apps. And since the DL32 and M32C communicate via AES50, they can be separated by CAT5 cabling, should that be more convenient for the venue.


  • 32 award-winning Midas PRO microphone preamplifiers with switchable 48 V phantom power
  • 16 electronically balanced low impedance line level outputs
  • ULTRANET personal monitoring system connectivity for in-ear applications
  • Dual ADAT outputs for use in splitter mode and stand-alone digital multicore applications
  • Two AES-3 ports (AES/EBU),e.g. for directly connecting PA system controllers with digital inputs
  • Remote operation up to 100 m via CAT5/5e cable
  • MIDI In/Out for bidirectional communication between FOH console and on-stage MIDI devices
  • Features Neutrik etherCON AES50 and ULTRANET network ports
  • Rugged 3U rackmount chassis for durability in portable applications
  • Auto-ranging universal switch-mode power supply
  • Mute-All-Inputs function for quietly patching any inputs on stage
