itel Power Tank All-in-one Solar Generator with 0.6kVA Inverter and 1kWh Lithium Battery (IESS-05K10N) - Brand New

The itel 500W Power Tank All-in-one Solar Generator (IESS-05K10N) is a compact solar generator designed for efficient energy production. It harnesses solar energy or the grid, providing a sustainable power solution for various applications. Ideal for both outdoor use and emergency situations, it promotes energy independence and reduces reliance on fossil fuels.

• Output Power: 600VA/ 500W
• AV Waveform: Pure Sine Wave
• Switching time: ≤20ms
• Battery Capacity: 1kWh (100A)
• Full load backup time: Up to 2 hours
• Battery type: LiFePO4
• Cycle life: 6000+ cycles
• Recharge time: Approximately 2 hours
• Solar input: Supported
• Use Scenario: Long duration backup
• Operating noise: 47dB

SPECIFICATIONS

PV INPUT

• Maximum PV Array Input Power: 400W (MPPT)
• Maximum PV Input Voltage Range: 60V
• MPPT Voltage Range: 11V ~ 60V

AC INPUT

• Maximum Grid Input Voltage: 380Vrms
• Input Voltage Range: 90VAC ~ 280VAC
• Maximum AC Input Power: 1000W (Bypass Mode+Battery charge)
• Maximum AC Input Current: 6A (Bypass Mode+Battery charge)
• Nominal Operating Frequency: 50/60Hz

AC OUTPUT

• Nominal AC Power (Inverter mode): 500W
• Maximum Output Apparent Power (Inverter mode): 600VA
• Nominal AC Output Voltage(Inverter mode): 230VAC
• Nominal AC Output Current (Inverter mode): 2.2A
• Nominal AC Output Frequency (Inverter mode): 50Hz
• Overload Capacity: CC 3A output @ >500W

BATTERY

• Battery Type: Lithium-ion, Lead Acid/ Tubular
• Rated Battery Voltage: 3.2VDC
• Rated Capacity: 314Ah
• Rated Energy: 1000Wh
• Cycle life: 6000

GENERAL

• Protection type: Overload, Surge, PV over voltage, Grid OVP, Battery fuse, Short circuit, Over-temperature and Battery fuse
• SOC Display: LED
• Cool Method: Intelligent fan cooling
• Noise: ≤47dB
• Authentication level: IEC62619/ IEC62368/ UN38.3
• Dimension (W x H x D): 225mm x 288mm x 139mm
